Manatee Pocket

Generation Date: 3/4/2026

Page 2

NOAA CUSTOM CHART

NOTES GEOSPATIAL DATABASE

VERSION 3.0B - 20 FEBRUARY 2025

The records of the NOAA Custom

Chart Notes Geospatial Database are

current as of February 20, 2025.

Subsequent additions and refinements

are to be expected. Please refer to

all

available

navigational

publications for complete information

about the charted area.

CAUTION

AUTOMATED CHART GENERATION

This NOAA Custom Chart has been

automatically

rendered

from

NOAA

Electronic Navigational Chart (NOAA

ENC®) data. Mariners using this NOAA

Custom Chart are advised that this is

a static reproduction of the NOAA

ENC®. This NOAA Custom Chart has not

been individually quality checked or

adjusted

for

optimal

use

for

navigation. The portrayal may be at a

different scale from that of the

original NOAA ENC®. Mariners are

advised to use caution when using

this NOAA Custom Chart for navigation

and are encouraged to use the latest

NOAA ENC® to access the most up-to-

date information. Mariners must also

comply with all applicable regulatory

requirements.

CAUTION

CHART UPDATES

This NOAA Custom Chart contains up-

to-date information only as of the

time of creation, and will become

outdated. Mariners are advised to

visit

https://

distribution.charts.noaa.gov/

navigation-updates/

to

check

for

critical and routine updates, and to

render a new NOAA Custom Chart when

the ENC data used to make the chart

is updated. Notices to Mariners are

not issued for corrections to this

NOAA Custom Chart.

HEIGHTS

Heights of fixed aids to navigation

and vertical clearances of overhead

obstructions will be shown in feet if

the units are set to feet or fathoms.

If units are set to meters, heights

will

be

shown

in

meters.

Land

elevation values are shown in meters

only.

AUTHORITIES

Hydrography and topography by the

National Ocean Service, Coast Survey,

with additional data from the Corps

of Engineers, Geological Survey, U.S.

Coast Guard and National Geospatial-

Intelligence Agency.

WATER LEVELS, CURRENTS, AND TIDES

Real-time

water

levels,

tide

predictions,

and

tidal

current

predictions are available on the

internet

from

NOAA’s

Center

for

Operational

Oceanographic

Products

and Services (CO-OPS) at https://

tidesandcurrents.noaa.gov/

water_level_info.html

and

https://

tidesandcurrents.noaa.gov/

currents_info.html .

COMMENTS REQUESTED

NOAA encourages users to submit

inquiries, discrepancies, or comments

about this chart via NOAA's ASSIST

tool

at

https://

nauticalcharts.noaa.gov/customer-

service/assist/ .

ABBREVIATIONS

For complete list of Symbols and

Abbreviations, see Chart No. 1.

Manatee Pocket

Generation Date: 3/4/2026

Page 3

POLLUTION REPORTS

Report all spills of oil and

hazardous substances to the National

Response Center via 1-800-424-8802

(toll free), or to the nearest U.S.

Coast Guard facility if telephone

communication is impossible (33 CFR

153).

AIDS TO NAVIGATION

Consult U.S. Coast Guard Light List

for

supplemental

information

concerning aids to navigation.

RADAR REFLECTORS

Radar reflectors have been placed

on many floating aids to navigation.

Individual

radar

reflector

identification on these aids has been

omitted from this chart.

WARNING

The prudent mariner will not rely

solely

on

any

single

aid

to

navigation, particularly on floating

aids. See U.S. Coast Guard Light List

and U.S. Coast Pilot for details.

ADDITIONAL INFORMATION

Additional information can be

obtained

at

www.nauticalcharts.noaa.gov

SUPPLEMENTAL INFORMATION

Consult U.S. Coast Pilot 4 for

important supplemental information.

Refer to charted regulation section

numbers.

SOUNDING DATUM

Soundings referred to Mean Lower

Low Water (MLLW).

VERTICAL DATUM

Overhead clearances are referred to

Mean High Water (MHW).

NOTE A

Navigation

regulations

are

published in Chapter 2, U.S. Coast

Pilot 4. Additions or revisions to

Chapter

2

are

published

in

the

Notices

to

Mariners.

Information

concerning the regulations may be

obtained

at

the

Office

of

the

Commander, 7th Coast Guard District

in Miami, FL or at the Office of the

District Engineer, Corps of Engineers

in Jacksonville, FL.

Refer to charted regulation section

numbers.

Manatee Pocket

Generation Date: 3/4/2026

Page 4

HURRICANES AND TROPICAL STORMS

Hurricanes, tropical storms and

other

major

storms

may

cause

considerable

damage

to

marine

structures, aids to navigation and

moored

vessels,

resulting

in

submerged

debris

in

unknown

locations. Charted soundings, channel

depths and shoreline may not reflect

actual

conditions

following

these

storms. Fixed aids to navigation may

have been damaged or destroyed. Buoys

may

have

been

moved

from

their

charted

positions,

damaged,

sunk,

extinguished

or

otherwise

made

inoperative. Mariners should not rely

upon the position or operation of an

aid

to

navigation.

Wrecks

and

submerged obstructions may have been

displaced

from

charted

locations.

Pipelines may have become uncovered

or moved. Mariners are urged to

exercise extreme caution and are

requested

to

report

aids

to

navigation discrepancies and hazards

to navigation to the nearest United

States Coast Guard unit.

INTRACOASTAL WATERWAY AIDS

The U.S. Aids to Navigation System

is designed for use with nautical

charts, and the exact meaning of an

aid to navigation may not be clear

unless

the

appropriate

chart

is

consulted. Aids to navigation marking

the

Intracoastal

Waterway

exhibit

unique yellow symbols to distinguish

them

from

aids

marking

other

waterways.

When

following

the

Intracoastal Waterway southward from

Norfolk, VA to Cross Bank, FL, aids

with yellow triangles should be kept

on the starboard side of the vessel

and aids with yellow squares should

be kept on the port side of the

vessel. A horizontal yellow band

provides no lateral information, but

simply identifies aids to navigation

as marking the Intracoastal Waterway.

OKEECHOBEE WATERWAY AIDS

The U.S. Aids to Navigation System

is designed for use with nautical

charts, and the exact meaning of an

aid to navigation may not be clear

unless

the

appropriate

chart

is

consulted. Aids to navigation marking

the

Intracoastal

Waterway

exhibit

unique yellow symbols to distinguish

them

from

aids

marking

other

waterways.

When

following

the

Okeechobee Waterway westward from St.

Lucie Inlet to Fort Myers, FL, aids

with yellow triangles should be kept

on the starboard side of the vessel

and aids with yellow squares should

be kept on the port side of the

vessel. A horizontal yellow band

provides no lateral information, but

simply identifies aids to navigation

as marking the Okeechobee Waterway.

CAUTION

Temporary changes or defects in

aids to navigation are not indicated

on this chart. See Local Notice to

Mariners.

CAUTION

LIMITATIONS ON THE

USE OF RADIO SIGNALS

Limitations on the use of radio

signals as aids to marine navigation

can be found in the U.S. Coast Guard

Light Lists and National Geospatial-

Intelligence Agency Publication 117.

Radio direction-finder bearings to

commercial broadcasting stations are

subject to error and should be used

with caution.

Manatee Pocket

Generation Date: 3/4/2026

Page 5

CAUTION

SUBMERGED CABLES AND PIPELINES

Additional uncharted submarine

pipelines and submarine cables may

exist within the area of this chart.

Not

all

submarine

pipelines

and

submarine cables are required to be

buried,

and

those

that

were

originally buried may have become

exposed. Mariners should use extreme

caution when operating vessels in

depths of water comparable to their

draft in areas where pipelines and

cables may exist, and when anchoring,

dragging or trawling.

Covered wells may be marked by

lighted or unlighted buoys.

NOAA WEATHER RADIO BROADCASTS

The NOAA Weather Radio station

listed

below

provides

continuous

weather

broadcasts.

The

reception

range is typically 20 to 40 nautical

miles from the antenna site, but can

be as much as 100 nautical miles for

stations at high elevations.

Fort Pierce, FL WWF-69 162.425 MHz

NOAA WEATHER RADIO BROADCASTS

The NOAA Weather Radio station

listed

below

provides

continuous

weather

broadcasts.

The

reception

range is typically 20 to 40 nautical

miles from the antenna site, but can

be as much as 100 nautical miles for

stations at high elevations.

West Palm Beach, FL KEC-50 162.475

MHz
